5 Days of Sage X3 Web Services (Day 4)

Sage X3 Web Services

Calling a Sage X3 Object From ASP.NET

This is part 4 of a 5 part series on creating and consuming web services for Sage X3. This post will focus on calling an Sage X3 Object from ASP.NET that has been exposed as a web service.

To review previous posts in the series, click the links below:

Day 1 – Setting up X3 Web Services
Day 2 – Creating X3 Web Services
Day 3 – Testing X3 Web Services
Day 5 - Calling a Sage X3 Program from ASP.NET

Now on to our current topic Calling a Sage X3 Object from ASP.NET ...

The wsdl for the X3 web services is below, where x3v6prmp23.rkldev.local is the server name where the web services are hosted.


Calling the SOH object via Web Services

Create the Call Context

The call context must be set prior to calling a web service, and is passed as part of the web service call. This is where the language, the X3 user and password, and the X3 connection pool name are set.

// Initialize Context

X3DataAccessConn.CallContextClass oCallContext = GetCallContext();

oCallContext.CallContext.requestConfig = "adxwss.trace.on=off&adxwss.trace.size=16384&adonix.trace.on=off&adonix.trace.level=3&adonix.trace.size=8";

CallContextClass GetCallContext()


// Initialize connection values

CAdxCallContext callContext = new

CAdxWebServiceXmlCCService webService = new

CAdxParamKeyValue[] paramKey = new

CAdxResultXml resultXML = new

callContext.codeLang = "ENG"; // Connection language

callContext.codeUser = "admin"; // X3 user

callContext.password = "pwd"; // X3 password

callContext.poolAlias = "NATRAINV6"; // Connection pool name

CallContextClass context = new
CallContextClass(callContext, webService, paramKey, resultXML);

return context;


Retrieve Order Details

The c# code below can be used to retrieve Sales Orders details from X3. The ResultXML will be an XML string that matches the SOH object screen. In the example below, the value in sSohNum is the X3 Sales Order Number.

// Reads a Single Sales Order with Details

X3_SalesOrderDetails cSalesOrd = new

_success = true;

_result = "";



// Initialize Connection Values

X3DataAccessConn.CallContextClass oCallContext = _connDetails.GetCallContext();

// Complete call context

oCallContext.CallContext.requestConfig = "adxwss.trace.on=off&adxwss.trace.size=16384&adonix.trace.on=off&adonix.trace.level=3&adonix.trace.size=8";

oCallContext.ParamKey = new

// Prepare paramKeyValue

oCallContext.ParamKey[0] = new

oCallContext.ParamKey[0].key = "0"; // Other method: paramKey[0].key = "SOHNUM";

oCallContext.ParamKey[0].value = sSohNum;

// Call web service

oCallContext.ResultXML = oCallContext.WebService.read(oCallContext.CallContext, serviceName, oCallContext.ParamKey);

if (oCallContext.ResultXML.status == 1)


cSalesOrd = ExtractSODetails(oCallContext.ResultXML.resultXml.ToString());



catch (Exception ex)


_success = false;

_result = ex.ToString();


return cSalesOrd;

If the order is found, the ResultXML string will be similar to below:

<?xml version="1.0" encoding="UTF-8"?>


    <GRP ID="SOH0_1" >

        <FLD NAME="SALFCY" TYPE="Char" >P21</FLD>

        <FLD NAME="SOHTYP" TYPE="Char" >SOL</FLD>

        <FLD NAME="ZSOHTYP" TYPE="Char" >Loan</FLD>

        <FLD NAME="SOHNUM" TYPE="Char" >SOL000004</FLD>

        <FLD NAME="REVNUM" TYPE="Integer" >0</FLD>

        <FLD NAME="CUSORDREF" TYPE="Char" ></FLD>

        <FLD NAME="ORDDAT" TYPE="Date" >20140226</FLD>

        <FLD NAME="BPCORD" TYPE="Char" >C2201</FLD>

        <FLD NAME="BPCNAM" TYPE="Char" >Beverly Hills Bike Shop</FLD>

        <FLD NAME="CUR" TYPE="Char" >USD</FLD>


    <GRP ID="SOH1_1" >

        <FLD NAME="BPCINV" TYPE="Char" >C2201</FLD>

        <FLD NAME="BPINAM" TYPE="Char" >Beverly Hills Bike Shop</FLD>

        <FLD NAME="BPCPYR" TYPE="Char" >C2201</FLD>

        <FLD NAME="ZBPCPYR" TYPE="Char" >Beverly Hills Bike Shop</FLD>

        <FLD NAME="BPCGRU" TYPE="Char" >C2201</FLD>

        <FLD NAME="ZBPCGRU" TYPE="Char" >Beverly Hills Bike Shop</FLD>

        <FLD NAME="BPAADD" TYPE="Char" >ST002</FLD>

        <FLD NAME="BPDNAM" TYPE="Char" >Beverly Hills Bike Shop</FLD>


    <GRP ID="SOH1_2" >

        <FLD NAME="PJT" TYPE="Char" ></FLD>


    <GRP ID="SOH1_3" >

        <LST NAME="REP" SIZE="1" TYPE="Char" >




    <GRP ID="SOH1_4" >

        <FLD NAME="LNDRTNDAT" TYPE="Date" >20140227</FLD>

        <FLD NAME="CCLREN" TYPE="Char" ></FLD>

        <FLD NAME="VACBPR" TYPE="Char" >NTX</FLD>

        <FLD NAME="ZVACBPR" TYPE="Char" >No Tax</FLD>

        <FLD NAME="CUR" TYPE="Char" >USD</FLD>

        <FLD NAME="ZCUR" TYPE="Char" >US Dollar</FLD>

        <FLD MENULAB="Ex tax" MENULOCAL="243" NAME="PRITYP" TYPE="Integer" >1</FLD>


    <GRP ID="SOH1_5" >

        <FLD MENULAB="Not Managed" MENULOCAL="280" NAME="APPFLG" TYPE="Integer" >4</FLD>

        <FLD MENULAB="Closed" MENULOCAL="415" NAME="ORDSTA" TYPE="Integer" >2</FLD>

        <FLD MENULAB="Not Allocated" MENULOCAL="416" NAME="ALLSTA" TYPE="Integer" >1</FLD>

        <FLD MENULAB="Shipped" MENULOCAL="417" NAME="DLVSTA" TYPE="Integer" >3</FLD>

        <FLD MENULAB="Invoiced" MENULOCAL="418" NAME="INVSTA" TYPE="Integer" >3</FLD>

        <FLD MENULAB="OK" MENULOCAL="419" NAME="CDTSTA" TYPE="Integer" >1</FLD>

        <FLD MENULAB="OK" MENULOCAL="491" NAME="HLDSTA" TYPE="Integer" >1</FLD>

        <FLD NAME="HLDBTN" TYPE="Char" >280</FLD>

        <FLD NAME="HLDCOD" TYPE="Char" ></FLD>


    <GRP ID="SOH1_6" >

        <FLD MENULAB="No" MENULOCAL="1" NAME="OCNPRN" TYPE="Integer" >1</FLD>

        <FLD MENULAB="No" MENULOCAL="1" NAME="BETFCY" TYPE="Integer" >1</FLD>

        <FLD MENULAB="No" MENULOCAL="1" NAME="BETCPY" TYPE="Integer" >1</FLD>


    <GRP ID="SOH2_1" >

        <FLD NAME="STOFCY" TYPE="Char" >P21</FLD>

        <FLD NAME="ZSTOFCY" TYPE="Char" >Bikes</FLD>

        <FLD MENULAB="Normal" MENULOCAL="410" NAME="DLVPIO" TYPE="Integer" >1</FLD>


    <GRP ID="SOH2_2" >

        <FLD NAME="DEMDLVDAT" TYPE="Date" >20140226</FLD>

        <FLD NAME="DAYLTI" TYPE="Integer" >0</FLD>

        <FLD NAME="SHIDAT" TYPE="Date" >20140226</FLD>


    <GRP ID="SOH2_3" >

        <FLD NAME="MDL" TYPE="Char" >GRN</FLD>

        <FLD NAME="ZMDL" TYPE="Char" ></FLD>

        <FLD NAME="BPTNUM" TYPE="Char" >UPS</FLD>


    <GRP ID="SOH2_4" >

        <FLD NAME="LASDLVNUM" TYPE="Char" >P211402SDL00000002</FLD>

        <FLD NAME="LASDLVDAT" TYPE="Date" >20140226</FLD>


    <GRP ID="SOH2_5" >

        <FLD MENULAB="Yes" MENULOCAL="1" NAME="ORDCLE" TYPE="Integer" >2</FLD>

        <FLD MENULAB="No" MENULOCAL="1" NAME="ODL" TYPE="Integer" >1</FLD>

        <FLD MENULAB="No" MENULOCAL="1" NAME="UNL" TYPE="Integer" >1</FLD>


    <GRP ID="SOH2_6" >

        <FLD MENULAB="Allowed" MENULOCAL="414" NAME="DME" TYPE="Integer" >1</FLD>


    <GRP ID="SOH2_7" >

        <FLD MENULAB="Detailed" MENULOCAL="450" NAME="ALLTYP" TYPE="Integer" >2</FLD>


    <GRP ID="SOH3_1" >

        <FLD MENULAB="One / Shipment" MENULOCAL="408" NAME="IME" TYPE="Integer" >1</FLD>


    <GRP ID="SOH3_2" >

        <FLD NAME="PTE" TYPE="Char" >NET30</FLD>

        <FLD NAME="DEP" TYPE="Char" ></FLD>

        <FLD NAME="ZDEP" TYPE="Char" ></FLD>

        <FLD NAME="SQHNUM" TYPE="Char" ></FLD>

        <FLD NAME="PRFNUM" TYPE="Char" ></FLD>

        <FLD NAME="LASINVNUM" TYPE="Char" >INV000147</FLD>

        <FLD NAME="LASINVDAT" TYPE="Date" >20140227</FLD>


    <TAB DIM="30" ID="SOH3_4" SIZE="3" >

        <LIN NUM="1" >

            <FLD NAME="SHO" TYPE="Char" >Freight</FLD>

            <FLD NAME="INVDTAAMT" TYPE="Decimal" >0</FLD>

            <FLD MENULAB="Tax excl" MENULOCAL="2227" NAME="INVDTATYP" TYPE="Integer" >1</FLD>


        <LIN NUM="2" >

            <FLD NAME="SHO" TYPE="Char" >Discount %</FLD>

            <FLD NAME="INVDTAAMT" TYPE="Decimal" >0</FLD>

            <FLD MENULAB="%" MENULOCAL="2227" NAME="INVDTATYP" TYPE="Integer" >3</FLD>


        <LIN NUM="3" >

            <FLD NAME="SHO" TYPE="Char" >Discount $</FLD>

            <FLD NAME="INVDTAAMT" TYPE="Decimal" >0</FLD>

            <FLD MENULAB="Tax excl" MENULOCAL="2227" NAME="INVDTATYP" TYPE="Integer" >1</FLD>



    <GRP ID="SOH4_2" >

        <FLD NAME="DLRNOT" TYPE="Decimal" >0</FLD>

        <FLD NAME="PFMTOT" TYPE="Decimal" >491.16</FLD>


    <GRP ID="SOH4_3" >

        <FLD NAME="ORDNOT" TYPE="Decimal" >3000</FLD>


    <GRP ID="SOH4_4" >

        <FLD NAME="ORDINVNOT" TYPE="Decimal" >3000</FLD>

        <FLD NAME="ORDINVATI" TYPE="Decimal" >3000</FLD>


    <TAB DIM="200" ID="SOH4_1" SIZE="1" >

        <LIN NUM="1" >

            <FLD NAME="NUMLIG" TYPE="Integer" >0</FLD>

            <FLD NAME="ITMREF" TYPE="Char" >21101</FLD>

            <FLD NAME="ITMDES" TYPE="Char" >Bicycle, R330, 54cm, Grey</FLD>

            <FLD NAME="ITMDES1" TYPE="Char" >Bicycle, R330, 54cm, Grey</FLD>

            <FLD NAME="DSTOFCY" TYPE="Char" >P21</FLD>

            <FLD NAME="SAU" TYPE="Char" >EA</FLD>

            <FLD NAME="QTY" TYPE="Decimal" >2</FLD>

            <FLD NAME="SAUSTUCOE" TYPE="Decimal" >1</FLD>

            <FLD NAME="STU" TYPE="Char" >EA</FLD>

            <FLD NAME="ALLQTY" TYPE="Decimal" >0</FLD>

            <FLD NAME="SHTQTY" TYPE="Decimal" >0</FLD>

            <FLD NAME="WALLQTY" TYPE="Decimal" >0</FLD>

            <FLD MENULAB="Detailed" MENULOCAL="450" NAME="DALLTYP" TYPE="Integer" >2</FLD>

            <FLD NAME="TDLQTY" TYPE="Decimal" >0</FLD>

            <FLD NAME="GROPRI" TYPE="Decimal" >1500</FLD>

            <FLD NAME="DISCRGVAL1" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL2" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL3" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL4" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL5" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL6" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL7" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL8" TYPE="Decimal" >0</FLD>

            <FLD NAME="DISCRGVAL9" TYPE="Decimal" >0</FLD>

            <FLD NAME="NETPRI" TYPE="Decimal" >1500</FLD>

            <FLD NAME="CPRPRI" TYPE="Decimal" >1254.42</FLD>

            <FLD NAME="PFM" TYPE="Decimal" >245.58</FLD>

            <FLD NAME="VACITM1" TYPE="Char" >NOR</FLD>

            <FLD NAME="VACITM2" TYPE="Char" ></FLD>

            <FLD NAME="VACITM3" TYPE="Char" ></FLD>

            <FLD NAME="REP1" TYPE="Char" >REP003</FLD>

            <FLD NAME="REPRAT1" TYPE="Decimal" >5</FLD>

            <FLD NAME="REP2" TYPE="Char" ></FLD>

            <FLD NAME="REPRAT2" TYPE="Decimal" >0</FLD>

            <FLD NAME="REPCOE" TYPE="Decimal" >1</FLD>

            <FLD NAME="DDEMDLVDAT" TYPE="Date" >20140226</FLD>

            <FLD NAME="DDAYLTI" TYPE="Integer" >0</FLD>

            <FLD NAME="DSHIDAT" TYPE="Date" >20140226</FLD>

            <FLD NAME="EXTDLVDAT" TYPE="Date" >20140226</FLD>

            <FLD NAME="DBPAADD" TYPE="Char" >ST002</FLD>

            <FLD NAME="CNDNAM" TYPE="Char" >000000000000005</FLD>

            <FLD NAME="USEPLC" TYPE="Char" ></FLD>

            <FLD MENULAB="Normal" MENULOCAL="410" NAME="DDLVPIO" TYPE="Integer" >1</FLD>

            <FLD MENULAB="Route Code 1" MENULOCAL="409" NAME="DDRN" TYPE="Integer" >1</FLD>

            <FLD NAME="DMDL" TYPE="Char" >GRN</FLD>

            <FLD NAME="DBPTNUM" TYPE="Char" >UPS</FLD>

            <FLD NAME="PRECOD" TYPE="Char" ></FLD>

            <FLD NAME="PCK" TYPE="Char" ></FLD>

            <FLD NAME="PCKCAP" TYPE="Decimal" >0</FLD>

            <FLD NAME="CCE1" TYPE="Char" ></FLD>

            <FLD NAME="CCE2" TYPE="Char" >BIKE</FLD>

            <FLD NAME="CCE3" TYPE="Char" >RESELLER</FLD>

            <FLD NAME="CCE4" TYPE="Char" ></FLD>

            <FLD NAME="CCE5" TYPE="Char" ></FLD>

            <FLD NAME="CCE6" TYPE="Char" ></FLD>

            <FLD NAME="CCE7" TYPE="Char" ></FLD>

            <FLD NAME="CCE8" TYPE="Char" ></FLD>

            <FLD NAME="CCE9" TYPE="Char" ></FLD>

            <FLD NAME="CCE10" TYPE="Char" ></FLD>

            <FLD NAME="CCE11" TYPE="Char" ></FLD>

            <FLD NAME="CCE12" TYPE="Char" ></FLD>

            <FLD NAME="CCE13" TYPE="Char" ></FLD>

            <FLD NAME="CCE14" TYPE="Char" ></FLD>

            <FLD NAME="CCE15" TYPE="Char" ></FLD>

            <FLD NAME="CCE16" TYPE="Char" ></FLD>

            <FLD NAME="CCE17" TYPE="Char" ></FLD>

            <FLD NAME="CCE18" TYPE="Char" ></FLD>

            <FLD NAME="CCE19" TYPE="Char" ></FLD>

            <FLD NAME="CCE20" TYPE="Char" ></FLD>

            <FLD MENULAB="Firm" MENULOCAL="317" NAME="DEMSTA" TYPE="Integer" >1</FLD>

            <FLD MENULAB="Stock" MENULOCAL="445" NAME="FMI" TYPE="Integer" >1</FLD>

            <FLD NAME="FMINUM" TYPE="Char" ></FLD>

            <FLD NAME="LINORDNOT" TYPE="Decimal" >3000</FLD>

            <FLD NAME="LINORDATI" TYPE="Decimal" >3000</FLD>

            <FLD NAME="LINPFM" TYPE="Decimal" >491.16</FLD>

            <FLD NAME="DETSQHNUM" TYPE="Char" ></FLD>

            <FLD MENULAB="Normal" MENULOCAL="423" NAME="LINTYP" TYPE="Integer" >1</FLD>

            <FLD MENULAB="No" MENULOCAL="439" NAME="FOCFLG" TYPE="Integer" >1</FLD>

            <FLD MENULAB="Closed" MENULOCAL="279" NAME="SOQSTA" TYPE="Integer" >3</FLD>

            <FLD NAME="DCCLREN" TYPE="Char" ></FLD>



    <GRP ID="ADB1_1" >

        <LST NAME="BPRNAM" SIZE="1" TYPE="Char" >

            <ITM>Beverly Hills Bike Shop</ITM>


        <FLD NAME="BPAADD" TYPE="Char" >ST001</FLD>

        <FLD NAME="CRY" TYPE="Char" >US</FLD>

        <FLD NAME="CRYNAM" TYPE="Char" >United States of America</FLD>

        <LST NAME="BPAADDLIG" SIZE="1" TYPE="Char" >

            <ITM>854 S Robertson Blvd</ITM>


        <FLD NAME="POSCOD" TYPE="Char" >90035</FLD>

        <FLD NAME="CTY" TYPE="Char" >Los Angeles</FLD>

        <FLD NAME="ITINERAIRE" TYPE="Char" ></FLD>

        <FLD NAME="SAT" TYPE="Char" >CA</FLD>

        <FLD NAME="CNTNAM" TYPE="Char" >000000000000005</FLD>

        <FLD NAME="ZCNTNAM" TYPE="Char" ></FLD>


    <GRP ID="ADB2_1" >

        <LST NAME="BPRNAM" SIZE="1" TYPE="Char" >

            <ITM>Beverly Hills Bike Shop</ITM>


        <FLD NAME="BPAADD" TYPE="Char" >ST002</FLD>

        <FLD NAME="CRY" TYPE="Char" >US</FLD>

        <FLD NAME="CRYNAM" TYPE="Char" >United States of America</FLD>

        <LST NAME="BPAADDLIG" SIZE="1" TYPE="Char" >

            <ITM>1053 Madison St</ITM>


        <FLD NAME="POSCOD" TYPE="Char" >98104</FLD>

        <FLD NAME="CTY" TYPE="Char" >Seattle</FLD>

        <FLD NAME="ITINERAIRE" TYPE="Char" ></FLD>

        <FLD NAME="SAT" TYPE="Char" >WA</FLD>

        <FLD NAME="CNTNAM" TYPE="Char" >000000000000005</FLD>

        <FLD NAME="ZCNTNAM" TYPE="Char" ></FLD>


    <GRP ID="ADB3_1" >

        <LST NAME="BPRNAM" SIZE="1" TYPE="Char" >

            <ITM>Beverly Hills Bike Shop</ITM>


        <FLD NAME="BPAADD" TYPE="Char" >ST002</FLD>

        <FLD NAME="CRY" TYPE="Char" >US</FLD>

        <FLD NAME="CRYNAM" TYPE="Char" >United States of America</FLD>

        <LST NAME="BPAADDLIG" SIZE="1" TYPE="Char" >

            <ITM>1053 Madison St</ITM>


        <FLD NAME="POSCOD" TYPE="Char" >98104</FLD>

        <FLD NAME="CTY" TYPE="Char" >Seattle</FLD>

        <FLD NAME="ITINERAIRE" TYPE="Char" ></FLD>

        <FLD NAME="SAT" TYPE="Char" >WA</FLD>

        <FLD NAME="CNTNAM" TYPE="Char" >000000000000005</FLD>

        <FLD NAME="ZCNTNAM" TYPE="Char" ></FLD>


    <GRP ID="ADXTEC" >

        <FLD NAME="WW_MODSTAMP" TYPE="Char" ></FLD>

        <FLD NAME="WW_MODUSER" TYPE="Char" ></FLD>



Submit the Order

Construct the XML for the Order Create:

// XML Header to be included in all xml input strings

string Cn_XMLHeader = "<?xml version="1.0" encoding="UTF-8"?>";

StringBuilder xmlInput = new



// Initialize Context

X3DataAccessConn.CallContextClass oCallContext = _connDetails.GetCallContext();

// Complete call context

oCallContext.CallContext.requestConfig = "adxwss.trace.on=off&adxwss.trace.size=16384&adonix.trace.on=off&adonix.trace.level=3&adonix.trace.size=8";

// Build xml string - starts with the fixed header


// Add customer code

addField(xmlInput, "BPCORD", so.SoldToCustNum);

// Add Customer Ref Nbr

addField(xmlInput, "CUSORDREF", so.CustPORefNbr);

// Add site code

addField(xmlInput, "SALFCY", so.SalesSite);

// Add order type

addField(xmlInput, "SOHTYP", hdr.Sohtyp_OrderType);

// Add Shipment site

addField(xmlInput, "STOFCY", so.SalesSite);

// Add Requested Delivery Date

addField(xmlInput, "DEMDLVDAT", hdr._demdlvdat_ReqDelDate);

// Add order lines

addLines(xmlInput, so.Lines);


// Call web service

oCallContext.ResultXML = oCallContext.WebService.save(oCallContext.CallContext, "ZSOH", xmlInput.ToString());

// Loop through results

foreach (CAdxMessage msg in oCallContext.ResultXML.messages)


_result += msg.message.ToString() + "^";



catch (Exception ex)


_success = false;

_result = ex.ToString();


if (_success == false) { _result += xmlInput.ToString(); }

The xmlInput string will look similar to below:


    <FLD NAME="BPCORD" >C3301</FLD>



    <TAB ID="SOH4_1" SIZE="2" >

        <LIN NUM="1" >

            <FLD NAME="ITMREF" >21304</FLD>

            <FLD NAME="QTY" >2</FLD>

            <FLD NAME="DSTOFCY" >P21</FLD>


        <LIN NUM="2" >

            <FLD NAME="ITMREF" >22301</FLD>

            <FLD NAME="QTY" >4</FLD>

            <FLD NAME="DSTOFCY" >D22</FLD>




If the order creation fails, the errors will be returned in the ResultXML.messages.

Need Help with Web Services?

Contact us if you want to learn more about Sage ERP X3 Web Services features or to request help with your system.

Contact RKL eSolutions

Sage X3 Web Services Guide

The Ultimate Web Services Guide For Sage X3

Want all 5 days in one comprehensive guide that you can download and take with you?

Leave your name below and we'll send you a copy of our Ultimate Guide to Sage X3 Web Services. This 38-page how-to manual provides everything you need to know about using X3 web services with screenshots, step-by-step instructions, and insider tips from our expert consultants.

Tags: Sage X3
Denise Hartman

Written by Denise Hartman

Denise has a B.S. in Business Administration from Millersville University, and an M.B.A. from Loyola University of Maryland and has been working at RKL eSolutions as a Sage Enterprise Management Engineer since 2007. Her main focus is on integrations between third party systems and Sage Enterprise Management. In her free time she enjoys spending time with her husband and adult twin daughters, who are both accountants.
